Integrated Amp
SKU: 20260619617-001
Rotel
RA-6000 Founder Edition (Black)
DT-6000 Founder Edition (Black)
B&W 702 S3 Signature (Datuk Highgloss)
Features
The Diamond Series RA-6000 Integrated Amplifier celebrates Rotel’s 60-Years of Japanese heritage. The RA-6000 supports a wide array of modern and legacy analog and digital sources delivering 350 watts of Class AB power into 4 ohms with exceptional acoustic detail and controlled rich, deep bass energy.
Digital inputs support 24-bit/192kHz audio streams. The asynchronous PC-USB input supports up to 32-bit/384kHz audio, decodes and renders MQA, and is fully certified Roon Tested. A Moving Magnet Phono stage is also included for vinyl fans.
Front panel controls, back-lit IR remote and 2-line display ensure intuitive operation.
Ethernet, RS232,12V trigger and external remote input simplify integration with control systems.
Specification
| Maximum Power Output | 350 watts/ch (4 ohms) |
| Continuous Power Output | 200 watts/ch (8 ohms) |
| Total Harmonic Distortion (THD) | < 0.0075% |
| Intermodulation Distortion (60 Hz : 7kHz, 4:1) |
< 0.03% |
| Frequency Response Phono Input Line Level Input |
20 Hz - 20k Hz, 0 ± 0.5 dB 10 Hz - 100k Hz, 0 ± 0.5 dB |
| Damping Factor (20 Hz - 20 kHz, 8 ohms) | 600 |
| Input Sensitivity / Impedance | |
| Phono Input (MM) Line Level Inputs (RCA) Line Level Inputs (XLR) |
5.2 mV / 47k ohms 340 mV / 5.6k ohms 540 mV / 100k ohms |
| Input Overload | |
| Phono Input (MM) Line Level Inputs (RCA) Line Level Inputs (XLR) |
52 mV 3.5 V 4.5 V |
| Standby Power Consumption | <0.5W |
| Preamplifier Output / Impedance | 1.9 V / 100 ohms |
| Intermodulation Distortion (60Hz:7kHz, 4:1) | <0.03% |
| Signal to Noise Ratio (IHF A-weighted) | |
| Phono Input (MM) Line Level Inputs |
80 dB 103 dB |
| Digital to Analog Converters | Texas Instruments |
| Power Consumption | 500W |
| Digital Section | |
| Frequency Response | 10 Hz - 90k Hz (0 ± 2 dB, Max) |
| Signal to Noise Ratio (IHF A-weighted | 102 dB |
| Input Sensitivity/Impedance | 0 dBfs / 75 ohms |
| Preamplifier Output Level | 1.43 V (at -20 dB) |
| Coaxial/Optical Digital Signals | SPDIF LPCM (up to 24-bit / 192k Hz) |
| PC-USB | USB Audio Class 2.0 (up to 32-bit / 384k Hz )* *Driver installation required Support MQA and MQA Studio (up to 24-bit / 384k Hz ) Roon Tested |
| Power Requirements | |
| USA EC |
60 Hz 50 Hz |
| Standby Power Consumption | |
| Normal Network Standby |
< 0.5 watts < 2 watts |
| BTU (4 ohms, 1/8th power) | 1239 BTU/h |
| Dimensions (W x H x D) | 431 x 144 x 425 mm 17 x 5 7/8 x 16 ins |
| Front Panel Height | 3U / 132.6 mm / 5 1/4 ins |
| Weight (net) | 18.81 kg, 41.47 lbs. |
| Finish | Silver and Black |
