Product Subwoofer Speaker B&W ASW-610 (BLACK ASH)
B&W
B&W :
ASW-610 (BLACK ASH)
Category : Subwoofer Speaker
Add to wishlist     สถานะสินค้า In Stock
ASW-610 (BLACK ASH)
ASW-610 (BLACK ASH)
ASW-610 (BLACK ASH)

PRICE :
31,900 THB.
SPECIAL :
29,900 THB.
ฟรีค่าขนส่ง

สอบถามสินค้า 02-103-1289,02-040-4229 เพิ่มเติม...
จำนวน ตู้

  • Overview

B&W ASW-610 (BLACK ASH)

The ASW610's long-throw 250mm driver allows it to move the large volumes of air needed for high-quality low-frequency output, and its audiophile-standard 200W Class D amplifier keeps the compact unit running cool.

The ASW610 subwoofer presents a very happy medium between the more diminutive ASW608 and the all-out power of the ASW610XP. Its long-throw 250mm driver allows the ASW610 to move the large volumes of air needed for high-quality low-frequency output, and its audiophile-standard 200W Class D amplifier keeps the compact unit running cool, even when the music or movie action is whipping up a storm.

In all of the 600 Series subwoofers, the bass driver diaphragms are constructed from a rugged, finely-tuned mix of paper pulp, Kevlar® fibres and resin, which provides the stiffness needed to withstand the tremendous physical forces exerted by the voice coil and pressures inside the cabinet.

Ultra-solid construction delivers slamming bass, drum kicks, and special movie effects. Deformation is minimised; bass precision, power and enjoyment are maximised.



http://www.piyanaswebboard.com/hosting/image-ACFE_5333E895.jpg

Specifications

Crossover Tuning
Mushrooms
Description Active closed-box subwoofer system
Drive unit ø250mm (10 in) paper/Kevlar® cone long-throw
Frequency range -6dB at 20Hz and 25/140Hz adjustable (EQ at A)
Frequency response ±3dB 27Hz – 40/140Hz adjustable (EQ at A)
Bass Extension -6dB at 20Hz (position A)
-6dB at 25Hz (position B)
-6dB at 30Hz (position C)

Power output: 200W
Rated power consumption: 40W / 0.5W standby
Input impedance: 33kΩ
Signal / noise: >90dB
Functions: Input level (line in)
Input level (speaker in)
Low-pass filter bypass
Bass extension
Bass roll-off alignment
Auto sense on/standby
Phase switch

Inputs: Line In (RCA Phono)
Speaker in (Binding post)
12v trigger (3.5mm jack)
Low-pass filter
Active 4th-order, variable cut-off frequency

Dimensions Height: 310mm (12.2 in) not including feet
Width: 310mm (12.2 in)
Depth: 375mm (14.8 in) including grille and controls

Net weight 12.5kg (27.6 lb)
Finishes Black
